C Purlin Machine, C Purlin Roll Forming Machine, Believe Industry

C Purlin Machine

Price :

$25,000.00

Description

C Purlin Machine

C Purlin Machine is a continuous line to produce various sizes of C Purlins as per desired requirements

M/C of C Purlin Machine

3 Ton Manual Uncoiler

  1. Coil width: 200-580 mm
  2. Coil I.D: 480 mm to 560 mm
  3. Max.capacity: 3 Ton
  4. Structure: Steel plate and Beam Welded
  5. Function: Supporting and uncoiling the steel strips

Feeding And Leveling

  1. Feeding type: Adjustable
  2. Width range:200-400 mm
  3. Feeding and guiding roller diameter: ¢65 mm
  4. Roller material: 45 # Steel With Quenched Treatment HRC 48-52, surface chromed
  5. Leveling roller: Upper 3, underneath 4 (totally 7 rollers)
  6. leveling roller: 45 # Steel With Quenched Treatment HRC 48-52, Chromed
  7. Diameter of leveling shaft: ¢76 mm
  8. Material of leveling shaft: 45# steelhardening and tempering

Roll Forming Machine

  1. Material thickness: 0.8-2.5 mm
  2. Main motor power:11 kw
  3. Forming speed: 8-12 m/min(not include cutting time)
  4. Quantity of stands: 14 stations
  5. Shaft material and diameter: ¢70 mm,45# steel
  6. Material of forming rollers: GCR 15
  7. Tolerance: +/-5 mm
  8. Type of drive: 1.5 inch single chain
  9. Total weight: About 10 Tons
  10. The width of the profile should be manual adjust

Hydraulic Cutting Device

  1. Cutting type: Hydraulic cutting
  2. Cutting power: 5.5 KW
  3. Working pressure: 12-16 Mpa
  4. Cutting motion:Roll Forming Part Is Non-stop When Cutting
  5. Material of Cutting Mould:Cr12 Steel With Quenched Treatment HRC 60-62, 3 groups
  6. Cutting Length and Quantity: Clients Set Length and Quantity on the PLC Touch Screen
  7. Tolerance of length: +/-5 mm

Hydraulic Station

  1. Hydraulic power: 5 KW
  2. Working pressure: 12-16 Mpa
  3. Hydraulic oil: 46# hydraulic oil
  4. Color:blue (or depend on per requirement)

Controlled System

  1. The worker input the length and quantity of the product through touch screen, total 20 groups, the touch screen will show the working status of the machine.
  2. Adopt Aviation Plug for easy connection
  3. Computer Control System: Panasonic PLC
  4. Encoder: Omron Brand
  5. Frequency Converter: Yaskawa
  6. Touch Screen: MCSG
  7. Controlled System Power: Overload Protection
  8. Pressure Of Hydraulic Station: ≧12 Mpa
  9. Current: 380 V Direct Current, 50 Hz, 3 Phase

Believe Industry Company have various types of C Purlin Machines for different requirements, for more information, please check more!

Additional information

Weight 65000 kg
Dimensions 8500 × 1200 × 1300 mm
