PORTABLE GUTTER MACHINE

Believe Industry Company have a full range of portable gutter machine for sale. 5″ and 6″ K style, 6″ half round gutter and 7″ industrial gutter machines.

Portable Gutter Machine For Sale

What’s A Gutter?

A rain gutter is a components of water discharge system for a building. Water from a roof flows down into a valley gutter, then goes down through downspout.  Many materials have been used to make gutters: Cast Iron, UPVC, Aluminum, Steel, Wood, Copper, etc.

Believe Industry Company portable gutter machine is able to produce gutter with the material of Copper, Alzc, PPGI and GI steel, with the thickness is from 0.3-0.5mm.

The Drawings of Gutters

Hale Round Gutters
K style gutter

3D View of Portable Gutter Machine

3d view of portable gutter machine
portable gutter machine for sale

Portable Gutter Machine Specifications

Main forming machine
Range of ProductsG5/6/5&6K
Forming stationFree Floating, 45# STEEL, heat treatment, coated with chrome
Main shaft materialS45C, heat treatment HRC42~44, Φ50mm
Cutting sheetCutting after forming ,Forward Pulling Manual Rack and Gear w/ Hardened tool Steel Dies
Forming speed0-10m/min
Producing speed0-6m/min
Main motor powerAC2.2KW, Chinese famous brand
Transmission systemUrethane top and bottom drive rollers for smooth even, non-twisting drive
Control systemSimple electrical control box
Dimension(L×W×H)Approx.3040×610×480 mm (not including package)
WeightApprox.490kg
Decoiler
Uncoiler typePassive un-coiler, built in main machine body together.
Uncoiler layoutBuilt in the body of main forming machine
CapacityMax.200kg
Expanding typeBy manual
Loading coilerBy manual
Coiler I.DΦ390-420mm
Coiler O.DMax.Φ1000mm
Coiler widthMax.400mm
Dimension(L×W×H)Approx.500×400×800 mm
WeightApprox.30kg
Electrical system
PLC brandNO
Operating tableButton
Length ControlEncoder
Quantity controlNO
Cutting motion controlSemi-automatic
Electrical componentsSiemens/Schneider
Encoder brandOmron, Japan
Inverter brandNO
Power supply3/4 HP; 110 VAC/50 Hz Single phase
Out-table
ApplicationSupporting for products
StructureWelding by angle steel, installed with round bar steel together.
Dimension(L×W×H)Approx..2000mm×500mm×400mm
Quantity1 pcs
PowerNo

Contact us now for more information.
